The specific conditions of the receiver operation call for a dedicated type of LiPo batteries – there is no need for extremely high discharge rates but low self-discharge and tolerance to irregular charging cycles and long term storage in fully charged state are essential. We are happy to introduce a special line of 5/10C, resp. 15/30C ManiaX LiPo batteries optimized for receiver use.
Do not use a charge rate higher than 2C, the recommended charge rate is 1C. We recommend using a balancer during every charge. ManiaX transmitter LiPo batteries do not require any initial forming; however, the initial three charging cycles should be performed at a rate not higher than 0.5C. There is no need to discharge the LiPo batteries before the charging - you can charge partly discharged packs.
The batteries are supplied as packs optimized for models featuring high torque/high speed servos. The packs feature heavy duty silicone power (charging) cables with the XT60 connectors and balance cables with JST-XH connectors that could be connected directly to the balance sockets of the most of KAVAN, SkyRC, GT Power etc. chargers.
The package contents: ManiaX battery pack, instruction manual.
Kapacita [mAh] | 450 |
Napětí [V] | 11.1 |
Nabíjecí proud [A] | 0.5 - 1.5 |
Max. nabíjecí proud [A] | 2.3 |
Vybíjecí proud [A] | 13.5 |
Max. vybíjecí proud [A] | 27 |
Energie [Wh] | 5 |
Délka [mm] | 58 |
Šířka [mm] | 30 |
Výška [mm] | 15 |
Hmotnost [g] | 44 |
